Telegartner J60020A0000 (100007379) Female Cat6a, RJ45 Connector, Shielded, Straight, Panel Mount Mount, TOC,

J60020A0000 TOC BULKHEAD SET IP68  AMJ-S MODULE CAT.6A T568B BRASS BODY NICKEL PLATED DOWNLOAD DATA      DOWNLOAD PDF     DOWNLOAD ASSEMBLY INSTRUCTION New Telegartner Part Number :- 100007379 Technical Attributes Description         Description         AMJ-S Module Cat.6A T568B Remarks              brass, nickel-plated Product description   TOC stands for Telecommunications Outdoor Connectors and offers cabling professionals the reliability and flexibility they need for toughest applications. The handy, easy to install TOC connectors are used for data- and telecommunications in mobile radio, process-, utility- and traffic automation, or security applications but also in the harsh environment of machine and plant engineering. The TOC series is available in nickel-plated brass for RJ45 Cat.6A and FO LC Duplex connectors. Compliance with the specifications of protection class IP68 and due to its excellent material properties, the TOC series can be installed even in harsh conditions within a temperature range from -40°C to 85°C. To lock, relief of strain and seal the connection, one turning movement is necessary and no further procedures are required. Customers benefit: a fast, error free and easy installation, high transmission reliability and resilience and more flexibility in the network design.   The TOC series RJ45 coming with the newly available field assembly RJ45 plug MFP8 Cat.6A and RJ45 keystone AMJ-S Module Cat.6A is available as a set. They can be attached to solid and stranded conductor cables with cable outer diameter max. 9.5 mm on site without the need for any special tools. For line extensions, the TOC Coupler IP68 is your first choice. It can be easily integrated with no negative effects on performance of the connection. Performance Characteristics       suitable for 10 Gigabit Ethernet acc. to IEEE 802.3an     suitable for PoE+ acc. to IEEE 802.3 at     360° shielding     temperature range: -40° to +85°C     protection class IP68 acc. to IEC 60529     protection cap with protection class IP68     RJ45 AMJ-S module Cat.6A acc. to IEC 60603-7-51 (500 MHz)     Cu-conductor: solid 0.4 - 0.64 mm (AWG26/1 – AWG22/1); stranded 0.46 - 0.76 mm (AWG27/7 – AWG22/7)     insulation diameter: 0.9 - 1.6 mm     4-hole mounting, mounting cut out Ø 30.5 mm     UL listed (E 244889)   Mechanical Characteristics Insertion force ≤ 30 N Durability (mating cycles)             ≥ 100 Material: housing             brass, 5 µm Ni plated Material: RJ45 insert       zinc diecast, nickel-plated Material: O-ring                silicone red Material: snap-fit             spring steel stainless Material: snap arm for cable trap              PC UL94 V0 black Material: slide for shield contact               PC UL94 V0 black Material: shield                 German silver Material: wire pair presorting     PBT UL94 V0 nature Material: insulating plate              PC UL94 V0 white Material: insulation body              PC UL94 V0 white Material: PCB     FR4 UL94 V0 Material: PCB finish         chem. tin-plated Material: contacts            spring steel Material: contact finish min. 0,8 µm Au on 1,2 µm Ni Material: contact IDC termination             CuNi2Si Material: IDC termination finish                 min. 3-6 µm Sn Material: protection cap IP68      brass, 5 µm Ni plated Cu-Conductor diameter: solid    0.41 - 0.64 mm AWG 26/1 - AWG 22/1 Cu-Conductor diameter: stranded           0.46 - 0.76 mm AWG 27/7 - AWG 22/7 Insulation diameter        1.0 - 1.6 mm Cable diameter                 4.0 - 9.5 mm Electrical Characteristics Current carrying capacity at 50°C               1 A PoE+ acc to IEEE 802.3at                Adequate for Power over Ethernet+ Standards Connectors         IEC 60603-7-51 Generic cabling systems               ANSI/TIA/EIA-568-C.2; ISO/IEC 11801; DIN EN 50173-1 Degrees of protection provided by enclosures (IP code)                IEC 60529 Transmission Characteristics 10 Gigabit Ethernet acc. to IEEE 802.3an                 Adequate for 10 Gigabit Ethernet Category 6A       ISO/IEC 11801, DIN EN 50173-1 Class EA                ISO/IEC 11801, DIN EN 50173-1 Category 6A       ANSI/TIA/EIA-568-C.2 Telegärtner – UK Distributor Connectors Cables Specialists  Between us we offer you the best contacts for your success Maximum customer orientation and unbroken force of innovation:  On this basis Telegärtner develops, produces and sells professional and tailor-made connection technology solutions as well as high-precision turned parts and plastic injection mouldings to customers all over the world.
