DMD-C Pressure controller

Selectable measuring range 0...100, 0...300, 0...500, 0...1000 Pa.

Pressure signal output 0...10 V and 4...20 mA.

Controls output 0...10 V.

Adjustable damping of the measuring signal.

Zero-point adjustment.

Microprocessor-controlled differential pressure transmitter for air and neutral gases. The unit has LED-display and built-in controlling function. The main application is for pressure control in air handling systems.

DMD-C has four different measuring ranges in the same unit, 0...100 Pa, 0...300 Pa, 0...500 Pa and 0...1000 Pa. The range is selected by means of buttons under the cover.

Supplied with 2 m plastic tube and two pressure outlets.

measuring range 0...100, 0...300, 0...500, 0...1000 Pa.

Additional information:

• Brand: Systemair
• Warranty: 1 year manufacturer's warranty
• Delivery: This item is usually stocked overseas and takes about 2 weeks to deliver. If held in UK stock, available for delivery in 3–4 days. Enquire on 01609 243164
