CJBD/ALF-2525-6M 1/5 Dust Control/Ventilation Unit

CJBD/ALF Ventilation Units with pre-lacquered sheet metal, built in filter and aluminum profiles.

Fan:

• CBD series double-inlet fans.

• Galvanised sheet steel.

• Structure with thermal insulation and soundproofing.

• Impeller with forward-facing blades made from galvanised sheet steel.

• Stuffing-box for cable inlet.

Motor:

• Class F closed motors with incorporated thermal protector, ball bearings and IP-54 protection.

• Single-phase 220-240V.-50Hz. and three-phase 220-240/380-415V.-50Hz.

• Max. air temperature to transport: -20°C.+ 60°C.

Finish:

• Anticorrosive pre-lacquered sheet steel and aluminium.

On request:

• With circular inlet.

Key features:

• Airflow: 2,200m³/h
• Power: 1.50A/0.15Kw/230V
• Noise Level: 54db(A)
• Weight: 39Kg

Additional information:

• Brand: Sodeca
• Warranty: 1 year manufacturer's warranty
• Delivery: This item is normally assembled to order in mainland Europe and delivered direct

Download PDF

For more information on CJBD/ALF-2525-6M 1/5 Dust Control/Ventilation Unit talk to Puravent
