MT-8103IE

10.1" TFT colour graphic touchscreen HMI. Bright 350 cd/m2 TFT LCD colour; widescreen 1024x600 pixel display. High resolution resistive touch screen; 16.7m colours. LED 50;000hrs long-life backlight. WiFi compatible with 8202.11b/g/n. Con.A: COM2 RS-485 2W/4W, COM3 RS-485 2W.Con.B: COM1 RS-232/ COM3 RS-232 (Only Tx & Rx (no RTS/CTS) may be used for COM1 RS-232 when COM3 RS-232 is also used). 1x USB 2.0; 1x 10/100Base-T EtherNet. 128Mb DRAM and 128Mb flash memory on-board. Isolated 24VDC?20% @650mA power required. RTC built-in. NEMA4 /IP65. Conformal coated PCB. Use EasyBuilder Pro for programming. Easy Access 2.0 Licence included.

For more information on MT-8103IE talk to Lamonde Automation Ltd
